Laser Marking Data: Based on [MAGIC-L2]

Writer's picture: Redt Inc.Redt Inc.

The current default settings have a large discrepancy compared to the values used on-site,

leading to repeated situations where new data needs to be provided. In the case of the MAGIC fiber laser marking machine, since the primary customers aredomestic and international jewelry-related businesses, It is necessary to modify the default settings to fit jewelry applications.


White Marking [Pure Gold, Copper] (+ Surface Smooting)


Power

Frequency

Speed

Repeat Count

40

25

1000

1

30

25

1000

1

Note: Default hatching gap is 0.02mm

Pure metals, like gold, react weakly to lasers, so a strong single pass roughens the surface, removing the gloss before performing white marking.



White Marking [Pure Gold, Sterling Silver] (+ Surface Smooting)


Power

Frequency

Speed

Repeat Count

40

25

1000

1

20

25

1000

1

Note: Default hatching gap is 0.02mm

Precious metals react weakly to lasers, so after one pass, apply a basic power of 20 for white marking.

White Marking [Metal]


Power

Frequency

Speed

Repeat Count

30

25

1000

1

20

25

1000

1

Note: Default hatching gap is 0.02mm

For metals with low reactivity to lasers, white marking may not be visible. Therefore, mark them with a stronger first pass, followed by a lighter marking.

White Marking [Plated Metal]


Power

Frequency

Speed

Repeat Count

20

25

1000

2

Note: Default hatching gap is 0.02mm Power around 20–30 can be used for white marking on most metals. Two passes are better for a whiter and clearer engraving, as one pass may lack clarity.



White Marking [Thin Plated Metal]


Power

Frequency

Speed

Repeat Count

20

25

1000

1

Note: Default hatching gap is 0.02mm

Mark lightly on plated surfaces to avoid peeling the plating (if too strong, the pink undercoat may be exposed).


Deep Engraving A [Precious Metal] - General


Power

Frequency

Speed

Repeat Count

100

25

1000

10

Note: Default hatching gap is 0.02mm

Standard deep engraving, with speed taken into consideration.



Deep Engraving A [Precious Metal] - For Coloring


Power

Frequency

Speed

Repeat Count

100

25

1000

14

Note: Default hatching gap is 0.02mm

Deep engraving for coloring purposes, such as on silver jewelry.



Deep Engraving A [Precious Metal] - High Quality


Power

Frequency

Speed

Repeat Count

100

25

50

6

Note: Default hatching gap is 0.02mm Engraving deeply in one go results in slightly better internal quality. Typically used for master copies. It is not highly significant for coloring purposes.

Steel Black Marking (Hatching 0.003)


Power

Frequency

Speed

Repeat Count

13

60

30

1

Note: Default hatching gap is 0.02 mm

A method that creates soot on the surface, leaving a slightly rough finish.



Steel Black Marking (Hatching 0.005)


Power

Frequency

Speed

Repeat Count

12

300

10

1

Note: Default hatching gap is 0.02mm

Changes the color without leaving soot, but the process is slow.




Steel Black Marking (Hatching 0.001) +2mm Or +2.5mm Focus Shift


Power

Frequency

Speed

Repeat Count

90

50

300

1

Note: Default hatching gap is 0.02mm

Offset the focus by +2.5mm to engrave. After confirming the position, adjust the height data only for engraving. It’s speculated that pulse values are corrected via arbitrary focus adjustment. It takes approximately 1 minute and 30 seconds to engrave an image on a 2.5cm pendant, resulting in a good black mark that appears to coat only the surface.




Active Black Marking (Hatching 0.005)



Power

Frequency

Speed

Repeat Count

90

50

300

1

Note: Default hatching gap is 0.02mm

Brass tends to char easily, so simply increasing the power causes black soot to appear.




Metal Cutting A [Above 1mm Thickness] (Beam thickness recommended)


Power

Frequency

Speed

Repeat Count

100

25

10

-

Note: Default hatching gap is 0.02mm Tapering occurs on thicker materials due to radial beam focus. Thicker beams are advantageous to reduce swelling or warping. Since cutting isn't done quickly, thermal deformation is more likely. Laser reactivity varies by metal or alloy.



Metal Cutting B



Power

Frequency

Speed

Repeat Count

100

25

100

1

Note: Default hatching gap is 0.02 mm

Slow, deep processing is more advantageous than faster processing.




Metal Cutting C [Below 0.5mm Thickness]



Power

Frequency

Speed

Repeat Count

100

25

1000

-

Note: Default hatching gap is 0.02 mm

Thin sheets warp with prolonged heat exposure.




Thermosetting Plastic ( Hatching 0.002)



Power

Frequency

Speed

Repeat Count

20

25

1000

1

Note: Default hatching gap is 0.02 mm

For plastics, swelling and melting may occur. If power is too high, swelling worsens, and at higher frequencies, melting occurs. Faster speed is better, but the Magic Engrave machine maxes out at a speed of 1000.




Thermosetting Plastic ( Hatching 0.004)



Power

Frequency

Speed

Repeat Count

20

40

1000

1

Note: Default hatching gap is 0.02 mm

Plastics that are highly reactive to energy require a wider hatching gap. Plastics are broadly divided into thermosetting and thermoplastic. Thermosetting plastics harden or burn under heat, allowing black soot or surface white marking, depending on the synthetic material. Thermoplastic, which melts under heat, boils, or liquefies. Thin letters engrave relatively well since the area exposed to heat is smaller, but wide areas can warp due to the heat.




Leather Marking (0.04mm) Natural Leather Only


Power

Frequency

Speed

Repeat Count

35

25

500

1

Note: Default hatching gap is 0.02 mm

A marking method that causes surface soot, with the risk of melting on coated surfaces. Therefore, synthetic leather and rexine are difficult to engrave, but some synthetic and natural leathers are engravable. If the engraving is too strong or doesn't show up, or if a gradation effect is needed, apply the photo-marking toolpath.


Leather Marking


Power

Frequency

Speed

No. of points

Repeat Count

35

25

500

10

1

Note

A marking method that produces soot on the surface may melt coated surfaces. Therefore, engraving on synthetic leather or rexine is challenging, and only certain synthetic or natural leathers are suitable for engraving.




White Marking [Plated Metal]



Power

Frequency

Speed

No. of points

Repeat Count

10

25

1000

10

1

Note:

Spot marking with default settings, a range of 8–12 is appropriate, while 20 is too strong. To enhance marking quality, create a photo marking toolpath by enlarging the target engraving area by 1.1–1.5 times before generating the toolpath. By reducing the generated toolpath, a more concentrated engraving in the same area is possible, allowing for more precise details. However, if the density is too high, it may result in poorer gradation expression due to the points being too closely packed.




Black Marking [Steel, Titanium]



Power

Frequency

Speed

No. of points

Repeat Count

13

300

10

800

1

Note:

Increase the for effective black marking.
